	MECHANICAL PROPERTIES									CHEMICAL COMPOSITIONS
Sr. No.	Specification	Grade	Relevan to	Range	Yield Stress (N/mm²)	Yield Stress (N/mm²)	% Elongation	Bend Test	Impact Test (J)	C %	Si % **	Min %	S %	P %	V or Nb %	CEQ %

1)	IS 2062	E-250A	for MS Materia	Max.	---	---	---	up to 25mm 2t and above 25mm 3t	NS	0.250	0.250	1.550	0.045	0.045	--	0.420
1)	IS 2062	E-250A	for MS Materia	Min.	250	410	23	up to 25mm 2t and above 25mm 3t	NS	0.100	0.115	0.600	---	---	---	---

2)	BSEN 10025	S275JR	for MS Material	Max.	---	560	---	NS	---	0.240	0.250	1.600	0.045	0.045	---	0.400
2)	BSEN 10025	S275JR	for MS Material	Min.	275	410	23	NS	27 at 20⁰	0.100	0.115	0.600	---	---	---	---

3)	BSEN 10025	S275JO	for MS Material	Max.	---	560	---	NS	---	0.210	0.250	1.600	0.040	0.040	---	0.400
3)	BSEN 10025	S275JO	for MS Material	Min.	275	410	23	NS	27 at 0⁰	0.100	0.115	0.600	---	---	---	---
